Base for welding 40x40/85x85mm, Raw

The Strofix base for welding 40×40 / 85×85mm, RAW is an AISI 304 stainless-steel square base plate for the 40 × 40 mm square railing post tube. The plate measures 85 × 85 mm and is 4 mm thick (h), supplied with a raw (unfinished) surface. The post tube is attached by welding.

The 85 × 85 mm square plate sits between the compact 80 × 80 mm and the larger 100 × 100 mm plates, giving a mid-size square footprint for the 40 × 40 mm post. This is the AISI 304 version; the same 85 × 85 mm plate is also offered in marine-grade AISI 316 and in lower-cost S235 mild steel. The raw surface is standard for base plates concealed by a decorative cover after installation. AISI 304 stainless steel suits standard interior and exterior installations.

Use cases:

• Floor mounting of 40 × 40 mm square railing post tubes with a mid-size plate
• Square base plate matching a square post profile for clean alignment
• Standard stainless-steel post base for residential and commercial railings
• 85 × 85 mm footprint between the compact 80 × 80 and larger 100 × 100 plates
• Welded square post bases concealed by a decorative cover

FAQ

What post tube does this base plate fit?

The 40 × 40 mm square post tube — the square railing post profile in the Strofix range.

What steel grade is used?

AISI 304 stainless steel. The same 85 × 85 mm plate is also available in AISI 316 (marine grade) and S235 (mild steel, lower cost).

What are the plate dimensions?

85 × 85 mm with 4 mm thickness (h). A square plate matches the square 40 × 40 mm post profile.

How does this compare to the other 85×85 versions?

This is the AISI 304 version (€3.03). The AISI 316 version offers marine-grade corrosion resistance at a higher price; the S235 version is mild steel at a lower price for coated or interior applications.

How is the post tube attached?

The post tube is welded to the base plate using TIG or MIG welding.

Why is the surface raw?

The raw finish is standard for base plates that are concealed by a decorative cover after installation.

About Base & Clamp Fastenings

A base or clamp fastening is a stainless-steel plate or bracket that anchors a railing post to the building structure, forming the structural foundation of the balustrade. Bottom fastenings bolt to the top of a floor slab, deck or beam, while side fastenings bolt to the vertical face of a fascia, edge beam or wall. Assembly clamps grip an existing tube or post without welding, and assembly plates provide a flat mounting surface for auxiliary connections.

Strofix supplies 18 base and clamp products for Ø42.4 mm round pipe and 40×40 mm flat-sided square posts, with plate diameters from Ø80 to Ø100 mm (round) and plate dimensions from 80×80 to 135×56 mm (rectangular/square), in satin or raw-surface stainless steel with AISI 304 and AISI 316 options.

Screw-hole configurations include 2, 3 and 4-hole variants. The correct fastening depends on mounting orientation, post profile, plate size, number of screw holes and the required surface finish.
