Glass railing system with glass adaptors for a flat surface - 42.4

The Strofix glass railing system with glass adaptors for a flat surface - 42.4 is a complete corner railing post supplied with 4 glass adaptors (point fixings) for holding the glass. It is made for flat-surface (level) mounting, with a 40 × 40 × 2 mm post standing H=1060 mm on a 108 × 108 mm base, and its top is configured for a round Ø42.4 mm tube handrail. Available in AISI 304 or AISI 316 grade with a satin finish.

This is the corner configuration: the post carries 4 glass adaptors to secure the glass panels that meet at the corner, forming a point-fixed glass balustrade. The "42.4" designation is the version for the round Ø42.4 mm tube handrail — a "Flat" version for the flat 40 × 40 handrail profile is also available. AISI 304 suits interior and standard exterior installations; AISI 316 contains added molybdenum for higher resistance to chlorides and salt air, making it the choice for coastal and high-humidity environments. It is a finished post system from the Strofix For Glass railing range, for level surfaces rather than stairs.

Use cases:

• Corner post for a point-fixed glass balustrade on a flat surface
• Glass railings topped with a round Ø42.4 handrail
• Glass railings on balconies, terraces, and landings
• Level-ground glass railing runs, not stairs
• Coastal and poolside glass railings (AISI 316 recommended)

FAQ

What is included?

The system is a corner railing post supplied with 4 glass adaptors (point fixings) for securing the glass.

What are the post dimensions?

The post is 40 × 40 × 2 mm and stands H=1060 mm on a 108 × 108 mm base.

What handrail does the "42.4" version take?

Its top is configured for a round Ø42.4 mm tube handrail. A "Flat" version for the flat 40 × 40 handrail profile is also available.

What surface is it for?

It is made for flat, level surfaces — not stairs. A separate For Stairs version is available.

What is the difference between AISI 304 and AISI 316?

AISI 316 contains added molybdenum for higher resistance to chlorides and salt air. Choose AISI 316 for coastal, pool, and high-humidity installations; AISI 304 is sufficient for interiors and standard outdoor conditions.

About Glass Railing Posts

A glass railing post is a stainless-steel vertical upright designed to hold glass panels as the infill of a balustrade, creating a transparent barrier on balconies, terraces, mezzanines and staircases. The glass is secured to the post either by integrated glass adaptors (through-bolt point fixings drilled into the glass) or by glass clamps, and a handrail sits on top to complete the system.

Strofix supplies glass railing post systems in flat (40×40 mm) and round (Ø42.4 mm) post profiles, for flat-surface and stair installations, all in AISI 304 or AISI 316 stainless steel with a satin finish.

Multiple system variants are available within each profile and surface combination, differing in glass-adaptor arrangement and the number of fixing points per post. The correct system depends on post profile, installation surface, glass fixing method and the panel size and weight to be supported.
