Glass railing system For stairs - Flat
€73.02 Tax excluded
€88.35 Tax included
€88.35 Tax included
Tax included
Steel grade
Quantity
| Steel grade | AISI304 AISI316 |
|---|---|
| Surface finish | Satin |
| Tube size | 40x40mm |
| Glass thickness | 8mm |
| Additional information | Other glass thicknesses on request - contact us |
| Post type | For stairs |
| Handrail type | Square profile 40x40mm |
A ready-to-install end post for stairs, H 960 mm – for a glass railing with glass clamps. Strofix welds it from AISI 304 stainless-steel parts: a 40 × 40 × 2 mm square post tube on a 100 × 100 mm base plate under a 110 × 110 mm cover. The post carries two 45 × 45 mm glass clamps on one face for the end of one glass panel – the lower clamp has a glass support.
On top: an M8 end cap, an adjustable handrail rod that follows the stair pitch, and a handrail plate for a 40 × 40 mm square handrail. The two fixing heights are 550 mm apart (centre to centre). Satin finish; also available in AISI 316. Glass, handrail and floor anchors are not included.
| Steel grade | SKU | Price excl. VAT | Price incl. VAT |
|---|---|---|---|
| AISI304 | MSS40960TTGS-04/1R | €73.02 | €88.35 |
| AISI316 | MSS40960TTGS-16/1R | €103.02 | €124.65 |
Use cases:
- End post of a glass railing with 8 mm glass in clamps
- Glass railings on stairs
- Start or finish of a railing run
FAQ
What is included?
The welded post (40 × 40 × 2 mm square post tube on the base plate), cover, 2 glass clamps, end cap, handrail rod and handrail plate. Glass, handrail and floor anchors are not included.
What glass thickness is it for?
The clamps are fitted for 8 mm glass as standard. If you need a different glass thickness, contact us – we can offer other thicknesses as well.
How far apart are the glass fixings?
The two fixing heights are 550 mm apart, centre to centre.
Which handrail does it take?
A 40 × 40 mm square handrail – the plate on top is shaped for it. A version for the Ø42.4 mm round handrail is also available.
How does it follow the stair pitch?
The handrail rod on top is adjustable, so the handrail plate can be set to the angle of the stairs.
What is the difference between AISI 304 and AISI 316?
AISI 316 contains added molybdenum for higher resistance to chlorides and salt air. Choose AISI 316 for coastal, pool, and high-humidity installations; AISI 304 is sufficient for interiors and standard outdoor conditions.
About ready-made railing posts
We weld our ready-made railing posts from the same stainless-steel parts we sell separately – post tubes, base plates, covers, glass clamps and glass adaptors, end caps and handrail plates. A railing run uses end and middle posts, plus corner posts where it changes direction.
Strofix quality
Strofix designs and supplies stainless-steel fastening systems for architectural glass, including glass adaptors, railing components, handrails, and structural fixings. We also serve architects, installers, and building contractors on residential and commercial projects.
The products we sell are designed by us, and manufactured under strict quality guidelines so that we can be sure our customers are getting exactly what they ordered.
All of our products meet EU quality standards. Our shipping partners provide convenient delivery times. For more on our return & warranty policy read here. Secure payments are provided by MakeCommerce.
